SUN-3/3.6/5K-SG04LP1-EU
3-5kW | Single Phase | 2 MPPT | Hybrid Inverter | LV Battery Supported
SUN-3/3.6/5K-SG04LP1-EU, hybrid inverter, is suitable for residential and light commercial use, maximizing self-consumption rate of solar energy and increasing your energy impendence. During the day, the PV system generates electricity which will be provided to the loads initially. Then, the excess energy will charge the battery via SUN 3/6K-SG04. Finally, the stored energy can be released when the loads require it. The battery can also be charged by the diesel generator to ensure uninterrupted supply in the event of grid blackout. It is equipped with RS485/CAN port for battery communication. Available as the Deye 3kW hybrid inverter, Deye 3.6kW hybrid inverter and Deye 5kW hybrid inverter, this single phase range is the popular pick for anyone comparing a 5kW hybrid solar inverter or 5kW solar inverter for home use in India — contact us for the Deye 5kW hybrid inverter price.
- Colorful touch LCD, IP65 protection degree
- AC couple to retrofifit existing solar system
- Max. 16 pcs parallel for on-grid and off-grid
- operation; Support multiple batteries parallel
- Max. charging/discharging current of 140A
- 6 time periods for battery charging/discharging
- Support storing energy from diesel generator
Product Specification
| model | SUN-3K-SG04LP1-24-EU | SUN-3K-SG04LP1-EU | SUN-3.6K-SG04LP1-EU | SUN-5K-SG04LP1-EU |
| Battery Input Data | ||||
| Battery Type | Lead-acid or Lithium-ion | Lead-acid or Lithium-ion | Lead-acid or Lithium-ion | Lead-acid or Lithium-ion |
| Battery Voltage Range (V) | 20~30 | 40~60 | 40~60 | 40~60 |
| Max. Charging Current (A) | 140 | 70 | 90 | 120 |
| Max. Discharging Current (A) | 140 | 70 | 90 | 120 |
| Charging Curve | 3 Stages / Equalization | 3 Stages / Equalization | 3 Stages / Equalization | 3 Stages / Equalization |
| External Temperature Sensor | Yes | Yes | Yes | Yes |
| Charging Strategy for Li-Ion Battery | Self-adaption to BMS | Self-adaption to BMS | Self-adaption to BMS | Self-adaption to BMS |
| PV String Input Data | ||||
| Max. DC Input Power (W) | 3900 | 3900 | 4680 | 6500 |
| Rated DC Input Voltage (V) | 370(125~500) | 370(125~500) | 370(125~500) | 370(125~500) |
| Start-up Voltage (V) | 125 | 125 | 125 | 125 |
| MPPT Range (V) | 150~425 | 150~425 | 150~425 | 150~425 |
| Full Load DC Voltage Range (V) | 300~425 | 300~425 | 300~425 | 300~425 |
| PV Input Current (A) | 13 | 13 | 13+13 | 13+13 |
| Max. PV ISC (A) | 17 | 17 | 17+17 | 17+17 |
| No. of MPP Trackers | 1 | 1 | 2 | 2 |
| No. of Strings per MPP Tracker | 1 | 1 | 1+1 | 1+1 |
| AC Output Data | ||||
| Rated AC Output and UPS Power (W) | 3000 | 3000 | 3600 | 5000 |
| Max. AC Output Active Power (W) | 3300 | 3300 | 3690 | 5500 |
| AC Output Rated Current (A) | 13.6/13 | 13.6/13 | 16.4/15.7 | 22.7/21.7 |
| Max. AC Output Current (A) | 15/14.3 | 15/14.3 | 18/17.2 | 25/23.9 |
| Max. Continuous AC Passthrough (A) | 35 | 35 | 35 | 35 |
| Peak Power (off grid) | 2 time of rated power, 10 S | 2 time of rated power, 10 S | 2 time of rated power, 10 S | 2 time of rated power, 10 S |
| Power Factor Adjustment Range | 0.8 leading to 0.8 lagging | 0.8 leading to 0.8 lagging | 0.8 leading to 0.8 lagging | 0.8 leading to 0.8 lagging |
| Rated Input/Output Voltage/Range(V) | 220/230 Vac (Single phase) | 220/230 Vac (Single phase) | 220/230 Vac (Single phase) | 220/230 Vac (Single phase) |
| Rated Input/Output Grid Frequency/Range | 50Hz/60Hz | 50Hz/60Hz | 50Hz/60Hz | 50Hz/60Hz |
| Grid Connection Form | L/`N/PE | L/N/PE | L/N/PE | L/N/PE |
| Total Harmonics Current Distortion (THDi) | <3% (of nominal power) | <3% (of nominal power) | <3% (of nominal power) | <3% (of nominal power) |
| DC Current Injection | <0.5% In | <0.5% In | <0.5% In | <0.5% In |
| Efficiency | ||||
| Max.Efficiency | 97.60% | 97.60% | 97.60% | 97.60% |
| Euro Efficiency | 96.50% | 96.50% | 96.50% | 96.50% |
| MPPT Efficiency | 99.90% | 99.90% | 99.90% | 99.90% |
| Protection | ||||
| Integrated | Anti-islanding Protection, PV String Input Reverse Polarity Protection, Insulation Resistor Detection, Residual Current Monitoring Unit, Output Over Current Protection, Output Shorted Protection, Surge Protection | Anti-islanding Protection, PV String Input Reverse Polarity Protection, Insulation Resistor Detection, Residual Current Monitoring Unit, Output Over Current Protection, Output Shorted Protection, Surge Protection | Anti-islanding Protection, PV String Input Reverse Polarity Protection, Insulation Resistor Detection, Residual Current Monitoring Unit, Output Over Current Protection, Output Shorted Protection, Surge Protection | Anti-islanding Protection, PV String Input Reverse Polarity Protection, Insulation Resistor Detection, Residual Current Monitoring Unit, Output Over Current Protection, Output Shorted Protection, Surge Protection |
| Over Voltage Category | DC Type II / AC Type Ⅲ | DC Type II / AC Type Ⅲ | DC Type II / AC Type Ⅲ | DC Type II / AC Type Ⅲ |
| Certifications and Standards | ||||
| Grid Regulation | IEC 61727, IEC 62116, CEI 0-21, EN 50549, NRS 097, RD 140, UNE 217002, OVE-Richtlinie R25, G99, VDE-AR-N 4105 | IEC 61727, IEC 62116, CEI 0-21, EN 50549, NRS 097, RD 140, UNE 217002, OVE-Richtlinie R25, G99, VDE-AR-N 4105 | IEC 61727, IEC 62116, CEI 0-21, EN 50549, NRS 097, RD 140, UNE 217002, OVE-Richtlinie R25, G99, VDE-AR-N 4105 | IEC 61727, IEC 62116, CEI 0-21, EN 50549, NRS 097, RD 140, UNE 217002, OVE-Richtlinie R25, G99, VDE-AR-N 4105 |
| Safety EMC / Standard | IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2 | IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2 | IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2 | IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2 |
| General Data | ||||
| Operating Temperature Range (℃) | -40 to +60℃, >45℃ Derating | -40 to +60℃, >45℃ Derating | -40 to +60℃, >45℃ Derating | -40 to +60℃, >45℃ Derating |
| Cooling | Free Cooling | Free Cooling | Free Cooling | Smart Cooling |
| Noise (dB) | ≤30 dB | ≤30 dB | ≤30 dB | ≤30 dB |
| Communication with BMS | RS485; CAN | RS485; CAN | RS485; CAN | RS485; CAN |
| Weight (kg) | 14 | 14 | 14 | 15.1 |
| Cabinet Size (WxHxD mm) | 330×433×238 (Excluding Connectors and Brackets) | 330×433×238 (Excluding Connectors and Brackets) | 330×433×238 (Excluding Connectors and Brackets) | 330×433×238 (Excluding Connectors and Brackets) |
| Protection Degree | IP65 | IP65 | IP65 | IP65 |
| Installation Style | Wall-mounted | Wall-mounted | Wall-mounted | Wall-mounted |
| Warranty | 5 Years | 5 Years | 5 Years | 5 Years |
Deye 3kW, 3.6kW & 5kW Hybrid Inverter in India
The SUN-3/3.6/5K-SG04LP1-EU is the Deye 3kW hybrid inverter, Deye 3.6kW hybrid inverter and Deye 5kW hybrid inverter in one single phase platform. It is the most searched Deye solar inverter for home use in India because a 5kW hybrid solar inverter covers the daytime load, battery charging and night-time backup of a typical 2–4 BHK house, villa or apartment.
As the Deye 3kW solar inverter, Deye 3.6kW inverter or Deye 3.6kW solar inverter it suits smaller rooftops of 3–4 kWp; as the Deye 5kW solar inverter — the Deye hybrid solar inverter 5kW model — it is regularly rated the best 5kW hybrid inverter India installers recommend, and the best 5kW solar inverter India homeowners can pair with dual MPPT, LV lithium battery support and up to 16 units in parallel. Every unit ships with the Deye inverter datasheet, specifications and installation guide.
Looking for the Deye 5kW inverter price, Deye 3kW hybrid inverter price or Deye 5kW solar inverter price in India? Festa Solar is an authorized Deye inverter dealer and distributor — share your location and battery requirement through the enquiry form and we will send the current Deye 5kW hybrid inverter price with a written quotation.
- Deye 3kW inverter for home — 1–2 BHK homes and small rooftops
- Deye 5kW inverter for home — 2–4 BHK homes, villas and apartments
- Deye hybrid inverter with battery for power-cut backup and self-consumption
- Retrofit of an existing on-grid plant via AC coupling
Frequently asked questions
What is the Deye 5kW hybrid inverter price in India?
Deye 5kW hybrid inverter price depends on the battery pairing, quantity and delivery location. Festa Solar shares dealer price and a formal Deye inverter quotation on request — use the enquiry form on this page.
Is the Deye 5kW hybrid solar inverter single phase?
Yes. The SUN-3/3.6/5K-SG04LP1-EU is a Deye single phase hybrid inverter with two MPPTs and 48V low-voltage lithium battery support.
Can I use a Deye 3kW inverter for home use without a battery?
Yes. The Deye 3kW / 3.6kW / 5kW hybrid inverter works as an on-grid inverter without a battery, and a Deye lithium battery can be added later for backup.
See the full Deye hybrid inverter range, browse all Deye solar products in India, or contact our dealer team for a Deye inverter quotation.
